Scale Working Boat Plans

Cornwall Model Boats | Model Boat & Ship Plans | Marine Modelling International |  Scale Working Boat Plans

Working Boats

The models in this category are of unique styles of small inshore and waterway based ships.
Please Note: These plans are printed to order and take approximately 7 days for us to obtain.

Difficulty Rating: One Star

One star means that the plan is an elementary design suitable for the beginner or first time plan builder.

 Marinette (Model Boat Plan)

Marinette (Model Boat Plan)

A scale French ‘Peniche’ Canal boat, drawn in detail, for bread and butter timber construction, electric drive and two function radio. At 1030mm length, 160mm beam, 1:32nd scale, to allow plenty of scale detail and individual finishing. Designed by Andre Moreau.

Featured in: MM June 1991
2 Star Difficulty Rating
Part No: MAR2287
More Information…

Price: £13.50 (Including VAT at 20%)
Euros: €15.31 (Inc VAT) / US Dollars: US$14.18 (Tax Free)


Quantity:

 Canadian Logpusher (Model Boat Plan)

Canadian Logpusher (Model Boat Plan)

A unique boat used in the Canadian lumber industry to move logs and modelled at 1:12th scale. Model size is 310mm by 140mm, designed for converted electric bow thruster unit. Makes a unique model full of colour and character. Designed by M Perrin.

Featured in: MM April 1991
1 Star Difficulty Rating
Part No: MAR2330
More Information…

Price: £11.00 (Including VAT at 20%)
Euros: €12.48 (Inc VAT) / US Dollars: US$11.55 (Tax Free)


Quantity:

 Ritalea (Model Boat Plan)

Ritalea (Model Boat Plan)

Freelance ‘Windermere’ style open launch, simple chine hull design, built in plywood. Model is 920mm in length and 235mm beam. Original used electric motor but could easily be converted to small steam unit. Two sheet plans, fully detailed. Designer Eric Leadley.

Featured in: Free Plan MMI January 2002
1 Star Difficulty Rating
Part No: MAR2919

Price: £16.00 (Including VAT at 20%)
Euros: €15.31 (Inc VAT) / US Dollars: US$14.18 (Tax Free)


Quantity:

Difficulty Rating: Two Stars

Two Stars means that some previous experience with kit or plans is desirable, or if you are a novice, some advice from an experienced modeller will be required.

Marine Modelling International Plan Shu'ai Dhow (Model Boat Plan)

Shu'ai Dhow (Model Boat Plan)

An Arabian Gulf Dhow to 1:24th scale, model of overall size 770mm x 150mm. Two sheets plans, well detailed. Both original and model are intended for electric motor and not sail power. Designed by Keith Edgar.

Featured in: MM April/May 1987
2 Star Difficulty Rating
Part No: MAR2097
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

 Fisher 25 (Model Boat Plan)

Fisher 25 (Model Boat Plan)

A scale motor yacht. Model 560mm loa. by 210mm beam, at 1:13.5 scale, plan shows all frames, side and plan view, and model may be built as a static boat, with two function radio. Designed by Don Hancock.

Featured in: MM May 1990
2 Star Difficulty Rating
Part No: MAR2302
More Information…

Price: £13.50 (Including VAT at 20%)
Euros: €15.31 (Inc VAT) / US Dollars: US$14.18 (Tax Free)


Quantity:

 Frasinul (Model Boat Plan)

Frasinul (Model Boat Plan)

A Romanian pilot and harbour boat at 1:25th scale, model 810mm length by 210mm beam, and 3.5kg weight. Full hull sections for planked hull shown and some building detail. A very attractive and portable model. Designed by Mircea Kiritescu.

Featured in: MM July 1991
2 Star Difficulty Rating
Part No: MAR2338
More Information…

Price: £13.00 (Including VAT at 20%)
Euros: €14.74 (Inc VAT) / US Dollars: US$13.65 (Tax Free)


Quantity:

 PS Wilton Castle (Model Boat Plan)

PS Wilton Castle (Model Boat Plan)

A model of a 1902 unique river paddlesteamer, built in Hay on Wye. Model is 1:16th, 3/4” to 1ft scale, 1200mm long and 190mm beam,and uses one or two electric motors for propulsion. Original and relatively easy to build. Designed by Eric Rawlins.

Featured in: MM January/February 1995
2 Star Difficulty Rating
Part No: MAR2433

Price: £13.00 (Including VAT at 20%)
Euros: €12.48 (Inc VAT) / US Dollars: US$11.55 (Tax Free)


Quantity:

 Blue Toon (Model Boat Plan)

Blue Toon (Model Boat Plan)

A two sheet plan of the Peterhead Pilot boat. At 1:25th scale the model is 700mm loa by 210mm beam, and is of an ideal size for a practical working scale boat. Designed by Jim Pottinger.

Featured in: MM December 1996
2 Star Difficulty Rating
Part No: MAR2526
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

 Pibroch Clyde Puffer (Model Boat Plan)

Pibroch Clyde Puffer (Model Boat Plan)

A 1:50th scale Clyde Puffer, of the Scotts of Bowling built ship. The model is 400mm. loa. and 112mm. beam, and fully detailed over two extensive sheets. A short feature in March 97 MM gives a little more information. Designed by Sandy Cousins.

Featured in: MM March 1997
2 Star Difficulty Rating
Part No: MAR2562
More Information…

Price: £18.50 (Including VAT at 20%)
Euros: €20.98 (Inc VAT) / US Dollars: US$19.43 (Tax Free)


Quantity:

 Aberdeen Pilot Boat No.2 (Model Boat Plan)

Aberdeen Pilot Boat No.2 (Model Boat Plan)

Two sheet plans at 1:20th scale. Model length 750mm, beam 260mm, round bilge planked hull. Designed by Jim Pottinger.

Featured in: Free Plan MM January 1998
2 Star Difficulty Rating
Part No: MAR2641
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:


Customers who bought this item also bought:
1. Grand Banks Motor Yacht (Ref: MAR3088)
 Nouveau (Model Boat Plan)

Nouveau (Model Boat Plan)

Two sheet plans for a 1:24th scale model, length 860mm and beam 210mm, of a modern high speed commuter launch of traditional lines. Canoe stern and twin motors require some previous experience. Designer Peter Massey.

Featured in: Free Plan MM! April 2002
2 Star Difficulty Rating
Part No: MAR2918
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

Marine Modelling International Plan Soleil D'or (Model Boat Plan)

Soleil D'or (Model Boat Plan)

Detailed drawings on two sheets for the unique Tresco Island motor launch. At 1:20 scale the model is 645 mm length and 170 mm beam. Full hull lines and deck layout but no model construction data. Designer Jim Pottinger.

Featured in: Free Plan in October 2005 MMI
2 Star Difficulty Rating
Part No: MAR3161
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

 Nancy Raymond (Model Boat Plan)

Nancy Raymond (Model Boat Plan)

Typical traditional Harbour Pilot Launch, built 1968 for Bristol Port by J L Thorneycroft. Plans on two sheets for a 1:24th scale model, length 690mm and beam 185mm, show original ship details but no model construction. Designer Jim Pottinger.

Featured in: Free Plan MMI July 2002
2 Star Difficulty Rating
Part No: MAR2982
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

 Landing Craft Ferry (Model Boat Plan)

Landing Craft Ferry (Model Boat Plan)

Mid 50’s aluminium landing craft style ferry, used in Sierra Leone. Plans on two sheets for a 1:24th scale model of 660mm length and 180mm beam, show plenty of ship detail but no model construction. Designer Jim Pottinger.

Featured in: Free Plan MMI October 2002
2 Star Difficulty Rating
Part No: MAR2984
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

Marine Modelling International Plan Jane Burnyeat (Model Boat Plan)

Jane Burnyeat (Model Boat Plan)

Two sheet plans for an estuary stores ferry workboat at 1:12 scale of 730 mm length and 190 mm beam. Full scale details shown but no model construction data. For single electric motor and R/C. Designer Jim Pottinger

Free Plan in October 06 MMI
2 Star Difficulty Rating
Part No: MAR3220
More Information...

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

Difficulty Rating: Three Stars

Three stars means that the plan involves methods that require a lot of knowledge and several previous models should have been completed before tackling this one.

Marine Modelling International Plan Minotaur (Model Boat Plan)

Minotaur (Model Boat Plan)

A 1:19th scale model of an Admiral’s Barge, circa 1900, 800m Loa. by 150mm beam, for RC and electric power. Designed by Roy Bullivant.

Featured in: MM January 1989
3 Star Difficulty Rating
Part No: MAR2239
More Information…

Price: £11.00 (Including VAT at 20%)
Euros: €12.48 (Inc VAT) / US Dollars: US$11.55 (Tax Free)


Quantity:

 Conservancy (Model Boat Plan)

Conservancy (Model Boat Plan)

A 1:16th scale Brook Marine 1958 40ft launch. Model is 770mm loa. by 200m beam, for single electric motor and two function RC. Designed by Dave Craggs.

Featured in: MM December 1989
3 Star Difficulty Rating
Part No: MAR2276
More Information…

Price: £13.00 (Including VAT at 20%)
Euros: €14.74 (Inc VAT) / US Dollars: US$13.65 (Tax Free)


Quantity:

 Bluebird 11 (Model Boat Plan)

Bluebird 11 (Model Boat Plan)

Cruising motor yacht built 1938 by G L Watson, the last of three for Sir Malcolm Campbell. Two sheet plans show all hull lines and superstructure. For experienced modellers as no construction information is included. Designer Jim Pottinger.

Featured in: August 2001 MMI
3 Star Difficulty Rating
Part No: MAR2904
More Information…

Price: £18.50 (Including VAT at 20%)
Euros: €20.98 (Inc VAT) / US Dollars: US$19.43 (Tax Free)


Quantity:

 Princess (Model Boat Plan)

Princess (Model Boat Plan)

High speed luxuy motor yacht. General lines and data on two sheets for experienced builders wanting a large scale model. Hull lines and superstructure at fullsize, but no model construction information. At 1:24th scale the model is 910m length and 235mm beam, suited to larger electric motors. Designer Jim Pottinger.

Featured in: June 2001 MMI
3 Star Difficulty Rating
Part No: MAR2905
More Information…

Price: £18.50 (Including VAT at 20%)
Euros: €20.98 (Inc VAT) / US Dollars: US$19.43 (Tax Free)


Quantity:

 Grand Banks Motor Yacht

Grand Banks Motor Yacht

Modern motor yacht on traditional lines. Hard chine design, length 595mm and 185mm beam, making for easy construction. Visible internal layout detailed, but no model construction. Designer Jim Pottinger.

Featured in: Free Plan in April 2004 MMI
3 Star Difficulty Rating
Part No: MAR3088
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:


Customers who bought this item also bought:
1. Aberdeen Pilot Boat No.2 (Model Boat Plan) (Ref: MAR2641)
Marine Modelling International Plan Tystie (Model Boat Plan)

Tystie (Model Boat Plan)

Single sheet plan for open steam launch. At 1:12 scale the model is 530 mm length and 62 mm beam and can be scaled up for steam power. Full details of original but no model construction data. Designer Jim Pottinger

Free Plan in April 06 MMI
3 Star Difficulty Rating
Part No: MAR3207
More Information...

Price: £11.00 (Including VAT at 20%)
Euros: €12.48 (Inc VAT) / US Dollars: US$11.55 (Tax Free)


Quantity:

 Princess of the Lake (Model Boat Plan)

Princess of the Lake (Model Boat Plan)

Lake District Cruise Launch based on Windermere. Basic model of 790 mm length and 200 mm beam construction shown but best for experienced modellers. Designer Peter Massey

Featured in March 07 MMI
3 Star Difficulty Rating
Part No: MAR3243
More Information...

Price: £15.50 (Including VAT at 20%)
Euros: €17.58 (Inc VAT) / US Dollars: US$16.28 (Tax Free)


Quantity:

Marine Modelling International Plan Norseman (Model Boat Plan)

Norseman (Model Boat Plan)

Chine hulled Scottish Salmon fishing boat at 1:20 scale of practical length to beam ratio length 675 mm and beam 280 mm. Plans for the original boat with no model construction data. Designer Jim Pottinger

Free Plan in October 2007 MMI
3 Star Difficulty Rating
Part No: MAR3258
More Information…

Price: £16.00 (Including VAT at 20%)
Euros: €18.14 (Inc VAT) / US Dollars: US$16.80 (Tax Free)


Quantity:

Marine Modelling International Plan Norman Mcleod Rodgers

Norman Mcleod Rodgers

A two sheet detailed plan of an icebreaking, supply and buoy tending vessel for service with the Canadian Department of Transport built in 1969.
This is for the experienced modeler, as yet a model has not been build of these plans.
DESIGNER: J. Pottinger

3 Star Difficulty Rating
Part No: MAR3406
More Information...

Price: £13.00 (Including VAT at 20%)
Euros: €14.74 (Inc VAT) / US Dollars: US$13.65 (Tax Free)


Quantity:

Difficulty Rating: Four Stars

Four stars means that the plans are for the most experienced modellers only, and that advanced techniques will be required to complete the model.

 M.Y. Pirate (Model Boat Plan)

M.Y. Pirate (Model Boat Plan)

Two sheet plans for a modern luxury motoryacht. At 1:48th scale the model is 890mm length and 160mm beam, ideal as a major project for experienced builders, with room for lots of detail. Designed by Jim Pottinger.

Featured in: MMI December 1998
4 Star Difficulty Rating
Part No: MAR2666
More Information…

Price: £18.50 (Including VAT at 20%)
Euros: €20.98 (Inc VAT) / US Dollars: US$19.43 (Tax Free)


Quantity:

 Fairway Dredger (Model Boat Plan)

Fairway Dredger (Model Boat Plan)

Double ended dumb barge with crane and grab. At 1:32nd scale model is 670mm Loa and 210mm beam. No model construction data. Designed by Jim Pottinger.

Featured in: Free Plan MMI November 2000
4 Star Difficulty Rating
Part No: MAR2834
More Information…

Price: £11.00 (Including VAT at 20%)
Euros: €12.48 (Inc VAT) / US Dollars: US$11.55 (Tax Free)


Quantity:

Cornwall Model Boats | Model Boat & Ship Plans | Marine Modelling International |  Scale Working Boat Plans
